Pressure type
|
Gauge pressure, Negative pressure, Absolute pressure
|
|
Range range
|
-1-0-1...400bar，customizable
|
|
Accuracy
|
≤±0.50%F.S.（Routine); ≤±1%F.S. Customizable precision
|
|
Electrical performance
|
Two wire system、Three wire system
|
|
Output signal
|
4~20mA | 0-5V | 0-10V | 0.5-4.5V | 10~90%Ratio
|
|
Supply voltage
|
8-32VDC | 8-32VDC | 12-32VDC | 8-32VDC/ 5VDC | 3.3-5.5VDC
|
|
Work temperature
|
-30℃~85℃
|
|
Storage temperature
|
-30℃~85℃
|
|
Electrical connection
|
Straight joint、Packard connector
|
|
Pressure connection
|
Internal thread: 7/16~20 UNF
|
|
External thread: 1/4" NPT、R1/4、G1/4"、 G1/2"、M14×1.5、M16×1.5、 M20×1.5
|
|
|
Customized: Thread specifications can be customized
|
|
|
Material
|
Shell: SUS304 stainless steel(standard)、 316 stainless steel(optional)、 customizable
|
|
Sensor: Ceramic (standard)
|
|
|
O shape seal ring: NBR(standard)、 FKM/CR/EPDM/(optional)
|
|
|
Overload pressure
|
150%F.S. customizable
|
|
Response time
|
≤20ms
|
|
long-term stability
|
0.1%F.S.±0.05%/year
|
|
Burst pressure
|
400% F.S. (P≤100bar); 200% F.S. (P≤400bar)
|
|
Insulation resistance
|
>100M Ω @50VDC
|
|
International Protection
|
IP65、IP67、IP68 customizable
|
