* Reverse polarity protection, transient overcurrent and overvoltage protection,
compliant with EMI protection requirements
* Excellent Water Tightness
* Wide pressure range coverage
* Multiple signal outputs, compatible with display meterscompliant with EMI protection requirements
| Parameters | Electrical characteristics |
|---|---|
| Pressure type | Gauge Pressure |
| Range | 0~0.1 m...0~200 mH₂O |
| Accuracy | ±0.5% FS; ±0.25% FS; ±0.1% FS; ±0.075% FS; ±0.05% FS |
| Electrical performance | Two wire system; Four wire system |
| Output signal | 4~20mA; RS485 Digital output |
| Power supply voltage | 24V DC; 12V DC (Optional) |
| Operating temperature | -40℃-80℃ |
| Storage temperature | -40℃-80℃ |
| Electrical connections | Straight Connection |
| Material quality - Housing | Stainless Steel; Customizable |
| Material quality - Sensor | Diffused Silicon/Ceramic |
| Material quality - O-shaped sealing ring | NBR / FKM / PTFE |
| Material quality - Cable | Polyethylene PE |
| Response time | ≤15ms |
| Overload pressure | ＞6~3×FS |
| Burst pressure | ＞10×FS |
| Long term stability | 0.25% FS / year |
| Cycle life | >1 million pressure cycles |
| Protection rating | IP68 |
| Working medium | Water, slurry, oil, milk, caustic soda, nitric acid, etc. |
