* Reverse polarity protection, transient overcurrent and overvoltage protection, compliant with EMI protection requirements
* Wide pressure range coverage
* Multiple signal outputs
* Intrinsically safe explosion-proof products comply with the requirements of GB3836.4 standard, with the explosion-proof mark Exia II CT6
| Parameters | Electrical characteristics |
|---|---|
| Pressure type | Micro positive pressure, Micro negative pressure, Differential pressure |
| Pressure range | -1 ~ 3.5 Bar (Customizable) |
| Accuracy | ±0.5% FS; ±0.25% FS |
| Electrical performance | Two wire system; Three wire system; Four wire system |
| Output signal | 4~20mA; 0-5V DC/10V DC; RS485 Digital output |
| Power supply voltage | 5V DC, 12V DC, 24V DC |
| Operating temperature | -20℃~80℃ |
| Storage temperature | -40℃~120℃ |
| Electrical connections | Hirschmann Connector |
| Pressure connection | Barbed hose connector Φ6×8mm |
| Material quality - Housing | Stainless Steel; Customizable |
| Material quality - Sensor | Diffused Silicon |
| Material quality - O-shaped sealing ring | NBR / FKM / PTFE |
| Response time | ≤10ms |
| Overload pressure | ＞10-3×FS |
| Burst pressure | ＞10×FS |
| Long term stability | <0.2% FS/year (Typical); <0.5% FS/year (Maximum) |
| Cycle life | >1 million pressure cycles |
| Protection rating | IP65, IP67 |
| Working medium | Silicone oil, non-conductive and non-corrosive gases |
