* Compact structure with excellent cost-performance ratio
* Algorithm compensation and correction technology
* Multiple signal outputs
* 150% F.S overload protection performance, strong impact resistance
* Supports customization of various specifications.
Product Parameters
Measuring range | -1-0-1…400 bar | |||
Pressure type | Gauge/Negative/Absolute pressure optional | |||
Material | SUS304 stainless steel, 316L stainless steel, copper, customization | |||
Sensor | Ceramic (Standard) | |||
Accuracy | ≤ ±0.50%F.S.(Routine);≤ ±1%F.S;Customizable Accuracy | |||
Overload Pressure | 150%F.S. | |||
Burst Pressure | 300%F.S. | |||
Working Temp | -30℃~85℃ | |||
Storage Temp | -30℃~85℃ | |||
Output | 4~20mA | 0~5V | 0~10V | 0.5~4.5V |
Power supply | 8~32V DC | 8~32V DC | 12~32V DC | 8~32V DC/5V DC |
Electronicl connection | Packard connector、Straight connection | |||
Pressure connector | 1/4" NPT, R1/4, G1/4", G1/2", M14×1.5, M16×1.5, M20×1.5, Customizable |
